Configure your product    ARPS3530K3RT2H-UN4-BK no found
?
CCT
Mounting
Optics
Voltage
Finish
Option
Performance Specifications
Initial Lumen Output: 2,973 lm
Efficacy: 84 lm/W
Luminaire Type: Type II-H - Medium
BUG Rating: B1-U0-G1
Environmental Rating(s): IP66
UL Classification: Wet Location Listed
Certification Standards: cULus
CCN Number: IFAM7.E359675
Limited Product Warranty: 10 Years
Light Source Specifications
Source Type: LED
CRI: >70
L70: 60,000 Hrs
Colour Temperature: 3000K
Electrical Specifications
Input Voltage: 347Vac
Input Frequency: 50-60Hz
Fixture Draw: 35 W
Surge Suppression: 10kV
Dimming: 1-10VDC - 10% Min Light Level
Physical Specifications
Finish Colour: Black
Finish Type: Textured powder coat over chromate conversion coat
Housing Material: ADC12 aluminium
Lens Material: PMMA
Weight: 4.7 kg
EPA: 1.39 sqft
Shipping Specifications
Box Quantity: 1
Box Dimensions (L-W-H): 495 x 340 x 180 mm
Box Weight: 4.7 kg
Series Architecture
Series Architecture img
