Product Configuration



This configuration tool allows you to adapt our product to your needs, using a variety of corresponding options. To configure your product, choose your desired options from the drop-down menus. Each selection will update the product specifications to reflect your choice.
Some options are not compatible (e.g. an integral occupancy sensor may not be available for a 347V input product), and as a result you won’t be able to select both options simultaneously. As with the previous example, if you selected 347V the occupancy option would not be visible. Conversely, if you selected an occupancy option, 347V would be similarly unavailable.
Not all configurations and options are stocked, and some may require minimum order quantities and lead times to produce. To inquire about availability, please call your local point of sale or contact us directly.

Catalog Number: ARPT8030KT2H-UN4-BK
no found
CCT
Optics
Voltage
Finish
Option
Download Specs
Not all configurations and options are stocked, and some may require minimum order quantities and lead times to produce. To inquire about availability, please call your local point of sale or contact us directly.
Product Specifications
Performance Specifications
Initial Lumen Output6997lm
Efficacy95lm/W
Luminaire TypeTCA_BUG_ARPT80-T2H_02.png
Environmental Rating(s)IP66
UL ClassificationWet Location Listed
Ambient Operating Temp-40C to +40C
Certification StandardsUL Safety US-CA
CCN NumberIFAM7.E359675
Limited Product Warranty10 Year(s)
Light Source Specifications
Source TypeLED
ManufacturerNichia®
Part NumberNVSW219
CRI>70
L7060000 Hrs
Colour Temperature3000K
Chromaticityx=0.4338 y=0.4030
Colour Tolerance3 SDCM
Duv0.005
Electrical Specifications
Driver ManufacturerInventronics®
Driver Part NumberESC-075S140DT
Input Voltage347Vac
Input Frequency50-60Hz
Fixture Draw72.52W
Current Draw@347Vac0.2105
Inrush Current1.3 A2S
Max On-Delay< 3 S
Auxiliary Control12 VDC
Power Factor @347Vac>.90
THD @277Vac(%)<10%
THD @347Vac(%)<15%
Driver MTBF61,900hrs
Max Operating Case Temperature90C
Surge Suppression10kV
Dimming1-10Vdc, (10% Min Light Level)
Dimming Current mA0.2
Over Temperature ProtectionAuto recovery. Current returns to normal after over temperature is removed.
Short Circuit ProtectionAuto recovery. The output shall return to normal when the fault condition is removed.
Driver Certificationsc-RU-us Class 2, FCC Part 15 Class B, RoHS
Physical Specifications
Finish ColourBlack (RAL-9011)
Finish Type Textured Powder Coat over Chromate Conversion Coat
WiringInternal Junction
Mounting2.375" O.D. Top Tenon
Housing MaterialADC12 Aluminium
Lens MaterialPMMA
Lens TypeClear Optics
EntriesGasketed Wire Entry
Shipping Specifications
OrderingCode(s)ARPT8030KT2H-UN4-BK
Box Quantity1
Box Dimensions (L-W-H)520 x 500 x 220 mm
Box Weight9.2 kg
Series Architecture
Series Architecture img
Optional ExtrasAR-N3PC-UN4
Downloads
TCA_IES_ARPT (258.3 KB)
TCA_BIM_ARPT (19.4 MB)
