CLY6-5CS-WH-ECO
CLY - Slim Disk Series
SKU CLY6-5CS-WH-ECO
Quantity
Fixture Type (Optional)
Add to Basket
Proceed to Basket
?
Add to basket to request a quote or save to a project folder
SKU CLY6-5CS-WH-ECO was added to basket
Product Specifications
Download Specs
Performance Specifications
Initial Lumen Output:
1,092 lm
Efficacy:
81 lm/W
Beam Angle:
110 deg
Luminaire Type:
Recessed - Direct
Environmental Rating(s):
IC Rated, Air Tight ASTM E283
UL Classification:
Wet Location Listed
Fire Rating:
.
Certification Standards:
cETLus, Energy Star, Air Tight (ASTM-E283), CAN ICES-005(B) NMB-005(B)
DLC Number:
.
CCN Number:
IFAO7.E470484
Limited Product Warranty:
5 Year(s)
Light Source Specifications
Source Type:
LED
CRI:
>80
Rf:
.
Rg:
.
L70:
>40,000 Hrs
L90:
>25,000 Hrs
Colour Temperature:
2700K, 3000K, 3500K, 4000K, 5000K Field Selectable
Electrical Specifications
Input Voltage:
120Vac
Input Frequency:
50/60 Hz
Fixture Draw:
13.50 W
Surge Suppression:
.
Dimming:
TRIAC (1-10Vdc, 10% Min Light Level)
Physical Specifications
Finish Colour:
White
Finish Type:
Powder Coated
Housing Material:
Die-cast Aluminium
Lens Material:
UV Stabilized Acrylic
Shipping Specifications
Box Quantity:
1
Box Dimensions (L-W-H):
182.118 X 182.118 X 59.944 mm / 7.17 X 7.17 X 2.36 in
Box Weight:
0.49 kg / 1.08 lbs
Carton Quantity:
12
Carton Dimensions (l-W-H):
340.106 X 197.104 X 378.968 mm / 13.39 X 7.76 X 14.92 in
Carton Weight:
5.91 kg / 13.01 lbs
