GR6-WH
EUD - Slim Disk Series
EUD6-SW-WH
EUD - Slim Disk Series
SKU EUD6-SW-WH
Quantity
Fixture Type (Optional)
Add to Basket
Proceed to Basket
?
Add to basket to request a quote or save to a project folder
SKU EUD6-SW-WH was added to basket
Product Specifications
Download Specs
Performance Specifications
Initial Lumen Output:
1250lm
Efficacy:
85lm/W
Beam Angle:
110 deg
Luminaire Type:
Direct
Environmental Rating(s):
IC Rated, Air Tight ASTM E283
UL Classification:
Wet Location Listed
Certification Standards:
cETLus, Energy Star, Air Tight (ASTM-E283), CAN ICES-005(B) NMB-005(B)
CCN Number:
IFAO7.E470484
Limited Product Warranty:
5 Year(s)
Light Source Specifications
Source Type:
LED
CRI:
>80
L70:
40000 Hrs.
L90:
25,000 Hrs.
Colour Temperature:
2700K, 3000K, 3500K, 4000K, 5000K Field Selectable
Electrical Specifications
Input Voltage:
120Vac
Input Frequency:
50/60 hz
Fixture Draw:
13.5W
Dimming:
TRIAC (1-10Vdc, 10% Min Light Level)
Physical Specifications
Finish Colour:
White
Finish Type:
Powder Coated
Housing Material:
Die-cast Aluminium
Lens Material:
UV Stabilized Acrylic
Shipping Specifications
Box Quantity:
1
