Product Configuration



This configuration tool allows you to adapt our product to your needs, using a variety of corresponding options. To configure your product, choose your desired options from the drop-down menus. Each selection will update the product specifications to reflect your choice.
Some options are not compatible (e.g. an integral occupancy sensor may not be available for a 347V input product), and as a result you won’t be able to select both options simultaneously. As with the previous example, if you selected 347V the occupancy option would not be visible. Conversely, if you selected an occupancy option, 347V would be similarly unavailable.
Not all configurations and options are stocked, and some may require minimum order quantities and lead times to produce. To inquire about availability, please call your local point of sale or contact us directly.

Catalog Number: RFJ654-3-WH
no found
CCT
Download Specs
Not all configurations and options are stocked, and some may require minimum order quantities and lead times to produce. To inquire about availability, please call your local point of sale or contact us directly.
Product Specifications
Performance Specifications
Initial Lumen Output1248 lm
Efficacy79.24 lm/W
CBCP467 cd
Beam Angle100 deg
Field Angle170 deg
Luminaire TypeSurface, Direct
Spacing Criteria1.22@(0-180) 1.22@(90-270)
Environmental Rating(s)IP20
UL ClassificationDamp Location Listed
Certification StandardscETLus, Energy Star
Limited Product Warranty3 Year
Light Source Specifications
Source TypeLED
CRI> 90
L7036000 hrs
Colour Temperature3000K
Electrical Specifications
Input Voltage120 Vac
Input Frequency60 Hz
Fixture Draw15.5 W
Current Draw@ 120Vac0.1550 A
DimmingTriac 100%-20%
Over Temperature ProtectionAuto Recovery, The fixture shall shut down and return to operation when the temperature returns to normal.
Short Circuit ProtectionAuto Recovery. The output shall return to normal when the fault condition is removed.
Driver Certificationsc-RU-us Class 2, FCC Part 15 Class B, RoHS
Physical Specifications
Finish ColourWhite
Finish TypePainted Aluminium
WiringBack, suitable for junction box
Mountingsurface
Housing MaterialAluminium
Lens MaterialAcrylic
Lens TypeFrosted
Shipping Specifications
OrderingCode(s)RFJ654-3-WH
Box Quantity1
Box Dimensions (L-W-H)190 x 190 x 80mm
Carton Quantity12
Carton Dimensions (l-W-H)585 x 390 x 175 mm
Downloads
Tamlite RFJ630-WH-OC - Installation Instructions - ENG (431.3 KB)
Tamlite RFJ630-WH-OC - Installation Instructions - FRN (428.2 KB)
Tamlite Lighting - RFJ654 Series - Installation Instructions - FRN (474.6 KB)
Tamlite Lighting - RFJ654 Series - Installation Instructions - ENG (470.4 KB)
