EVK-LY330SN-24V
EVKLY Series
SKU EVK-LY330SN-24V
icon
icon

Quantity
Fixture Type (Optional)
Add to Basket
?
Add to basket to request a quote or save to a project folder
SKU EVK-LY330SN-24V was added to basket
Proceed to Basket
Product Specifications
Download Specs
Performance Specifications
Initial Lumen Output:
3 @ 430lm
Efficacy:
43lm/W
Beam Angle:
120 deg
Luminaire Type:
Direct
UL Classification:
Wet Location Listed (heads only)
Limited Product Warranty:
5 Year(s)
Light Source Specifications
Source Type:
LED
CRI:
> 90
L70:
> 50000 Hrs
Colour Temperature:
3000K
Electrical Specifications
Input Voltage:
120Vac
Input Frequency:
50-60Hz
Fixture Draw:
45W
Internal Circuits:
3 @ 10W each
Dimming:
Not Suitable for Dimming
Physical Specifications
Finish Colour:
Satin Nickel
Finish Type:
Powder Coated
Housing Material:
Aluminium
Lens Material:
PMMA
Reflector Material:
Micro Dot
Shipping Specifications
Box Quantity:
1
Box Dimensions (L-W-H):
435 x 147 x 84mm
Carton Quantity:
4
Carton Dimensions (l-W-H):
450 x 310 x 192 mm
Downloads
EVKLY Series_Installation Instructions (208.2 KB)
